- Impedance: 4 ohms
- Frequency Range: 35 Hz – 1000 Hz
- Sensitivity: 94 dB to 97 dB (1W/1m, varies slightly by specific configuration)
- Voice Coil: 100 mm (4-inch) inside/outside copper voice coil on a fiberglass former
- Maximum Excursion (\(X_{max}\)): 9 mm
- Weight: 12.7 kg to 13 kg (approx. 28 lbs)
Design & Construction Highlights
- Motor Design: Features an aluminum demodulating ring to significantly reduce distortion and improve thermal heat dispersion.
- Suspension: Uses a double silicone spider and a triple-roll surround to maintain linearity and elasticity even after extended, heavy-duty use.
- Cone: Features a specialized radial cone with water-resistant treatment on both sides for durability in various environments.
